metal halide fixtures 9/29/08
Maybe I overlooked it, as well as undereducated in some aspects, but can metal
halide ballasts and hoods made for growing plants indoors (hydroponic farms) be
used with different bulbs over aquariums? <Mmm, with some provisos, yes...>
The reason I ask is that I have come across a place where I can get some 400w
metal halide ballasts and hoods for a ridiculously cheap price. <Well... can
you really use such high energy use, waste heat producing units?> I don't
have any experience with metal halide systems, but am researching them for my
new 150g <Mmm, not likely a good idea here... too high wattage for this
size, depth... more downsides than use... I would stick with 250 Watt or less
units> reef tank that I have and am still in the process of setting up - my
3rd reef tank. Are there specific bulb sizes I should make sure the ballasts
accept? <Oh yes...> Thanks for any insight. <Mmm... and issues re
water- and splash-proofing... the long and short of this, by and large I would
use only "aquarium intended fixtures". Read here:
http://wetwebmedia.com/marsetupindex2.htm the last couple of trays. Bob
Fenner>
Using Metal Halides 1/24/08
I just purchased an 48" Outer Orbit 2 150 watt 10 K HQI-MH w 2 130 watt 6
Lunar lights. I have a 90 gallon 24" deep aquarium. I had a nova extreme t-5 54
watt x 8. I didn't have very good luck with it staying on after about 6 months.
<Not good.>
I have my tank stocked with some fish and a few corals which consist of a torch
coral, a colt coral, a toadstool and some mushrooms. I
have it hanging 6" above my tank right now. Is that enough or should I raise it
more and to what height?
<Sounds like a good distance, you can always raise it a bit if you have
temperature issues.>
I would like to start raising a clam or two and some more stony corals.
<Will be fine, I would try to place the clams (especially Maximas or Croceas) in
the upper half of the tank.>
Thanks for your help crew, Bob L.
<Welcome, happy reefing, Scott V.>
MH lighting for a 125gal 6'
long tank 11/5/07
Dear WWM crew,
First of all thanks for your continued excellent support for the reef keeping
community. Keep up the good work.
<Thank you Isaac.>
Now onto my question, I'm moving from a 37gal FOWLR tank to a 125gal reef, that
is a 6 foot long tank. I will be keeping mostly LPS corals
and clams. Don't know if I want to keep SPS, most likely not.
Now comes my lighting dilemma. Since the tank has a big ugly brace right smack
in the middle, if I get 3x 175W MH lights will the middle light be
blocked out and mostly wasted?
<The light is still very usable, although not quite as intense. You will need to
clean the center brace periodically, it will make a big difference in light
penetration.>
(I'm not interested in designing and making my own hood, so I will only get
pre-made ones.) The other option is I could get 2x 250W (in pendants, possibly
going with PFO), but obviously this will exceed the commonly suggested 2 feet of
linear tank length per MH bulb.
<I have seen this done with this particular sized tank. It works, but you will
have to stock the tank accordingly considering that the center will have
noticeably less light. Just depends on the look you are after.>
For the animals I want to keep, is this going to be sufficient, not enough PAR
or even overkill (is even 2x 175W enough?).
Besides tank inhabitant health and growth, what about aesthetics? Will the 2x MH
lights create too much lapse?
<It really depends on your personal taste. If you want the tank to look uniform
I would go with the 3 X 175W. This will be plenty if stock you clams in the
upper half of the tank.>
P.S. Color temp will be in the
10k-13k range.
Thanks,
Isaac
<Happy reefing, Scott V.>
SW Lighting, reading re MHs - 7/23/07
Dear WWM crew members,
<Pedro>
I appreciate all of your wonderful support and knowledge. I have a question on
metal halide lighting for a 90 gal reef tank. If I wanted to keep SPS such as
acropora spp. would a 2x250watt 14k MH fixture 8"-9" from the surface be too
intense for the coral if placed in the upper half of the tank?
<Mmm, nope>
Or knowing that the lighting fixture would be 8"-9" above the surface of the
tank, would I be better off having a 2x150watt MH?
<Depends... you could "match" other aspects of husbandry to the higher wattage
fixtures... but if you "had time", weren't interested in boosting metabolism...
You could get by easily with the 150's>
If I had a 2x150w metal halide fixture about 8-9 inches from the surface, would
I still be able to place corals anywhere in my tank? Please notify me ASAP. It
would be helpful if you guys/gals could tell me which is better, 2x150w or
2x250w for SPS and other corals.
Peter
<Please read here: http://wetwebmedia.com/marsetupindex2.htm
the tray at the bottom. Bob Fenner>
Interchangeability Of Components Of Coralife
Aqualight Fixtures – 07/19/07
I'm setting out on a new adventure... a 180gal reef tank.
<<Cool!>>
It will replace my 55-gal reef tank (all residents will eventually be
transplanted to the new, larger tank). I've worked out all the details, pricing,
etc... except for one thing. I have an opportunity to get a great deal (less
than half price) on a Coralife Aqualight Pro.
<<I see>>
It's the 72" fixture with three 150W 10K's.
<<Should do nicely>>
The tank will have these residents:
Galaxea
Pagoda Cup
T. Crocea
T. Derasa
There are several others, but these are the ones in need of the most light by
far.
<<Okay>>
Also, they would be kept high in the tank (except the T. Derasa clam, he likes
his sand).
<<Indeed>>
Questions:
1) Will three 150W 10K's be enough? (My math says no since that's only 2.5Wper
gal).
<<The “watts per gallon” logic for determining lighting requirements is really a
very poor method in my opinion. There are so many factors that determine “what
is adequate”...e.g. water depth, water clarity, requirements of the individual
organisms, color temperature, feeding, etc. If you were planning to keep shallow
water Acroporids I would suggest more wattage; and even then not because the
corals couldn’t live under your planned configuration, but because I think they
would “color” better under the higher wattage lamps. But with what you have
listed, the 150W lamps w/10,000K bulbs will be fine>>
2) If I take the two ballasts and bulbs from my current tank's Coralife
Aqualight Pro (48" fixture with two 250W 10K's and ballasts to match), could I
replace two of the 150W ballasts/bulbs with the 250W ballasts/bulbs?
<<You could...but you will also have to change out the bulb brackets/holders as
these for the differing wattages are not compatible/interchangeable>>
Are the internal components of the fixtures compatible or would I burn something
out?
<<Being from the same manufacturer it is highly likely they are virtually
identical on the inside but for the ballasts/bulbs/brackets>>
3) If what I discussed in question 2 is a possibility, would the resulting 650W
total be enough for these residents (3.6W per gal)?
<<More than, yes>>
If not, what should I shoot for? Any brand/model recommendations?
<<I think you are fine with the 72” fixture mentioned>>
Thanks so much!
~Eric
<<Happy to assist. EricR>>
Re: pix of the day, magma MH use –
06/11/07
Very true, it does change weekly. I don’t dare to venture into the
possibilities of next month. Off the top of your head, do you think 2 400w MH
and 2 110w VHO actinics are too much for a 75 gallon?
<Yikes! Too hot (temp. and electrical cost) for me...>
I am wondering if I might be better off with what I already have.
<For now... BobF>
MH Lighting Choices - 3/27/07
Hi there, You guys are the best.
<Thank you for this, my friend. JustinN with you today.>
I have a 125 gallon reef ready system. Live sand, Live rock. Right now I just
have a goby, cleaner shrimp, and tomato clown. I am wanting to get into
inverts, and corals.
I need a stronger lighting system.
<Ok>
I am looking at a 785 watt. (3x175 MH and 2x130 watt blue actinic), or a 1134
watt (3x250 MH, and 4 96 watt blue actinic) each with led moonlights. Is there
such a thing as overkill with lighting?
<Certainly>
Which would you recommend. They are both 72", and have external ballasts. and
about $150 difference. They are Odyssea lights. I know it depends on what kind
of corals, or inverts I want to keep.
<Bingo>
But should I just go with the bigger one and be able to support light for just
about anything.
Is there any other tips you can give me on lighting situations. This is my
first adventure into MH's.
Thanks for any advice.
Aaron
<Well, Aaron, my thought is that the 3x250w would be overkill. I have a good
friend who runs a 120g beautiful reef, and has lit it for over a year using the
2x175w solution that Odyssea offers with great success. Of the two fixtures in
question, I would likely go with the smaller. Less heat to deal with, save
yourself some money as well. Hope this helps! -JustinN>
Metal Halide size and T5 question 3/1/07
Hi, Larry here.
<BobF here, hello>
I have a standard 75g 48" reef tank with softies and a few LPS under PC
lighting. I want to make the jump to SPS and clams. I have the opportunity to
buy a MH fixture with 2x250w HQI MH's and 2x96w actinic PC's. Is this going to
be too much light for my softies an the 3 fish and shrimp in the tank.
<Mmm, can be acclimated to this amount, kind of light for this size, shape
system... either by elevating fixtures or using screening likely... unless you
have dimmable "ballasts">
I'm also concerned about the heat issue. I have considered a fixture with dual
150w HQI MH with the 96w PC's. Which do you recommend?
<A tough one... as both can/will work...>
I can get the 250w fixture at a big discount. I was also thinking about Nova
extreme HO T5 fixture 432watts with 8x54w T5 bulbs, 4x460nm actinics and
4x10,000k bulbs. Will the T5 lighting be enough for SPS and Clams?
<It too could work>
The T5's are nice because you have so many lighting options because of the 8
bulbs. They also generate less heat and the bulbs supposedly don't have to be
replaced as often.
Thanks again for your help.
<Well... you do have a choice to make... Don't know that sorting through the
many articles and FAQs files on marine light/ing on WWM will help here... If it
were me/mine, and I had any notion that I might one day upgrade to an even
larger system... I'd go with the 150 watt MH's. Bob Fenner>
Re: Metal Halide size and T5 question, Flagfin angel dis./recovery
3/1/07
Thanks Bob for the prompt reply,
<Welcome Larry>
I think I'm going to go with the 150 HQI due to heat issues. I just needed to
make sure that I could keep SPS and clams.
<Ahh, this would be my choice as well>
I'd like to share a success story with you about a sick fish since you here so
many failures by hobbyists.
<Please do>
I have had a beautiful Flag Fin angel for 3 years. It became ill when one of my
older fish died and I didn't find out till 2 days later. The angel developed
bilateral cloud eye, fin rot, hemorrhagic patches on both sides of its abdomen
and mouth. I immediately place it in my QT tank. It progressed very rapidly and
the fish just labored at the top of the tank. It was literally knocking at
deaths door and I thought about euthanizing it. I started treatment right away
with 2 antibiotics, penicillin and furan along with every other day FW and
methylene blue dips and every other day water changes to my QT tank. Well now I
call the angel the miracle fish. Its almost back to normal except for some
residual damage to one eye. This fish did not eat for 12 days and now its
swimming around the tank and just starting to peck at food. Its not completely
out of the woods yet, but if it starts to eat again I just may get lucky.
<Yes... your diligence has paid well>
By the way, I'm a emergency medicine physician and my wife and friends are
calling me the fish doctor.
Have a great day and thanks for the help.
Larry
<A good title. BobF>
MH Upgrade...Options/Considerations - 01/18/07
Thanks for all the help over the past few years!!!
<<Has been a pleasure to assist>>
I am running (4) 65 Watt PC bulbs, two 10,000K bulbs and two Blue actinic.
<<Ok>>
I have a few LPS and mushrooms and about 6 fish in a 100 gallon tank.
<<Mmm, this lighting seems a bit "weak" to me for this size tank...even
considering the livestock you have>>
The tank has about 100lbs of live rock and my sand bed is about 3-4" deep. My
tank size is 23" tall by about 60" wide and about 18" deep. I want to add MH
lights to this aquarium and add SPS, but probably no clams.
<<Okay...do think to acclimate your livestock to the new/more intense lighting
when you do this. Have a read here beforehand:
http://www.wetwebmedia.com/acclimcoralslight.htm >>
I was wondering if running (2) 250watt MH bulbs with 10K to 14K bulbs would be
enough, or should I keep a set (2 bulbs) with 65watt actinic also with this
set-up?
<<The halides in either Kelvin temperature would be fine on their own, but many
folks opt to keep actinics in their tanks as well to enhance the "glow" of their
corals...and for my use, they're handy for "softening the blow" when the halides
go out at the end of the day when set to come on a bit before, and go off a bit
after, the main lights>>
I have a chiller that I have not hooked-up yet, but it is available.
<<Very good...though not always a necessity>>
Is 250watts too much, or would 175watts be better?
<<Depends much on the particular needs of the livestock you will ultimately
have, as well as depth of placement re, water clarity, even what Kelvin
temperature/bulb type/bulb manufacturer you choose. The 175-watt, and even
150-watt halides would probably suffice for most instances...but I would likely
choose the 250-watt halides myself for this tank just for the added flexibility
(wider range of intensity available by adjusting the fixture up/down)>>
Also, how high should I place the bulbs over the tank?
<<Usually 8" - 12", also dependent upon the factors already mentioned for
wattage selection>>
I want to put them in my enclosed hood as a retro fit.
<<Mmm, I see...that may change my thoughts then. In my experience enclosed
hoods with metal halide lighting are quite limiting. The distance between the
water and the bulb is usually "fixed" and often quite close...exacerbating the
issues of excess heat, mineral buildup in the bulbs or UV filters, even bulb
breakage from splashed water. Not to mention ventilation is usually not the
best...especially if the hood was not originally "designed" for metal halides
bulbs. I'm not trying to discourage you from making this
change/modification...just wanting to make you aware of the challenges re. With
these considerations in mind, the lower wattages might be the better choice>>
The hood has fans, so heat should not be a problem.
<<You'd be surprised...do consider adding extra fans or openings for additional
air flow>>
I just don't want to burn the other corals.
<<Acclimate them as explained in the article I referenced you to read>>
Also, how long should I run the lights during the day and how long to run them
for acclimation purposes?
<<Anything between 10 - 14 hours per day should be ok...I tend to run mine at
the longer end of the spectrum (six bulbs on for 11-hours individually but with
30-minutes between sequenced on/off timers...13 1/2 hours from the time the
first halide comes on till the last goes off)
Also, these are one-sided bulbs and not double-ended bulbs so I was wondering
also if I should place them perpendicular or parallel to the tank?
<<Ah, okay...so probably the 175-watters then. Parallel to the tank/hood is the
most common installation here. Two bulbs will be "stretching it" as far light
coverage goes, depending on the quality of the reflector in the hood and the
ultimate distance from the water's surface of the bulbs you may find you need
three bulbs for adequate coverage/an even "look">>
Thanks,
Jeromy
<<Quite welcome. Eric Russell>>
MH lighting, mis-stocking in a too small SW system 11/19/06
I am trying to make sense out of what I am about to say to you guys,
<Appreciated>
anyways I recently purchased a second 150 watt energy savers unlimited tank
mount metal halide because one did not cover my entire 58 gallon reef tank.
The occupants are a golden angel,
<Mmm... aurantius? Needs much more room>
two percula clowns, yellow goby, and a dwarf hog. Coral are elegance,
<Dangerous to crowd, have in small volumes>
hammer, mushrooms, xenia, and a toadstool,
<Do be diligent here re water changes, switching out chemical filtrants... I
would not add any other invertebrate life.>
there's 300 watts of light total and for one thing it seems to be to much for
the angelfish,
<Yes... I would only use one such fixture here>
also my electric bill is going up more than I thought it would,
<You are wise to be aware here>
so I was thinking instead of buying a new set of lighting could I reduce the
length of time the lights are on right now its about nine hours a day, or could
I get away with just using one halide and centering it,
<This is what I would do>
that would give me 150 watts of light. I also forgot to mention that there is a
rose bubble anemone in the tank, Thanks Ron
<... you should take the time to read re each of these listed species "Systems",
"Compatibility"... on WWM... some potential disaster looming. Bob Fenner>
Re: MH lighting, mis-stocking in a too small SW system 11/20/06
After writing to you I am considering taking some animals out whats the
logical move Thanks Ron.
<To read as you've been instructed... determine "who stings who" most... what
you'd like to, can keep together. BobF>
Photo-Shock? - 10/29/06
Good Morning... or afternoon, or evening, whatever it may be.
<<Hello...morning now>>
I am in a real mental pinch here with my halides and looking for a shoulder to
lean on (hopefully not cry on).
<<Let's see if I can be of assistance...>>
I think I goofed big time, but then again, it's reef keeping so before I jump
into trying to fix things, I thought I would ask someone with a little more
experience first.
<<Ah yes...go slow and research/analyze your options whenever possible>>
Here is the skinny. I just undertook a two-month project to build my dream
system.
<<Only two months? <grin> >>
Got the okay from the wife and took the plunge.
<<An "always important" component>>
I had a 105G tall (32"-deep X 48"-long) for three years with a 30G sump/fuge
combo. I keep acros mostly,
<<…me too>>
and have around 18 different species as well as a few other SPS, a rose bubble,
and a Crocea.
<<Ack! You were doing so well up until the anemone...>>
In my 32" tank I had 2X400W halides about 10" off the water and life was good.
<<A lot of light>>
Currently I have framed a 125G (6 foot long X 22" deep) display into a wall and
made a 12X6 foot support room behind it.
<<Cool! Love "in-wall" displays (is what I have)>>
The display has a 100g sump, 75g refugium, 30g prop tank, and I even got to tie
in my 30g anemonarium which was really great.
<<Lots of water volume...excellent>>
I drip Kalk 24/7, dose 2ml of iodide daily, and maintain a daily avg of: 425 CA,
9 DKH, 1.026 SG, 8.28 - 8.36 pH, 79.3 - 79.6 degrees, 0 nitrates, 0 PO4.
<<Very good>>
I use RO/DI that I aerate/buffer as needed and change 20G of water every
Sunday. I am very happy with my parameters, however I am not so happy with my
corals.
<<...!>>
Since I had the 2X400W halides from my deep tank, I just picked up another
reflector/ballast/bulb and am now using 3X400W halides over my 125G display,
which is only 22" deep.
<<Mmm...>>
I had the halides at 10ish-inches from the water surface that I now realize, or
think at least was way too close and have moved them to 16.
<<Indeed…the corals could have been/can be "acclimated" to the light intensity,
but this would need to be a "gradual" process. The organisms we keep are quite
adaptable...but they don't usually handle "rapid" changes well>>
I have noticed that my Pocillopora and a couple of Acros that made the
transition have started to lose their rich color for a more "watery"
color. Some red/pinks are fading to white, blues have gone pale, my rose bubble
just sticks a couple of tentacles out of a crack in a rock, etc. Nothing is
bleached; they are just not how they should be.
<<Does sound like photo-shock>>
At first I thought the color change was because I switched from XM 20Ks to
Radiums when I setup the new system, however I noticed that my best colored
coral is a purple-rim/green M. capricornis that sits almost directly under the
center brace. Also the more I have been reading on WWM the more I think that
the power/distance is the real culprit.
<<...?>>
To cut to the chase here, am I "making lava" as Anthony calls it, keeping the
400s?
<<400-watt halides are definitely more light than you need on a 22"-tank, but by
raising the fixtures/acclimating the organisms it can be utilized>>
Should I downgrade to 250, or do you think that the 400 at a higher set point
will be all right?
<<Downsizing the lighting will be cheaper to run/less excess-heat hassles...but
the 400-watt lighting can be used as stated>>
Perhaps I have missed the boat entirely and you think that something else might
be going on?
<<This too is a possibility, or at least a contributor...reactions to changes in
water chemistry, feeding, additives, or just being moved/repositioned in the new
system. But I think the lighting (due to lack of proper acclimation re) is
likely the main cause for the changes in color/behavior you describe>>
I am all ears and can't even begin to tell you how much I appreciate your time
to read this long-winded email and already feel better knowing that one of you
at WWM is going to chime in on this issue.
<<No worries mate...is what we do. Have a peek here re acclimating your corals
to the new lighting:
http://www.wetwebmedia.com/acclimcoralslight.htm>>
Again, all my gratitude, have a good morning/day/night =)
Jeff
<<Happy to share. EricR>>
LIGHTING CHANGE
Short and simple, crew. I currently have 360 watts of Comp Fluorescents
over
a 90 gallon. I am interested in a 2 x 250w, 10,000K Halides, with 2 x 96w
actinics. Is it too much, would I be better off with 175's? <Simple answer is
that it depends on what you want to do with the lights, what animals you wish to
keep. MacL>
Wanting to downgrade lighting
Hi Bob,
<< Blundell today. >>
I have a 36"L x 18"W x 30"H tank with 5" DSB. Planning to change my 2 x 250W SE
MH lights to something else due to the high electricity consumption and heat
contributed by the Metal halides. Would like to find out what other alternatives
do I have in order to meet the minimum requirements of a 30" depth with mostly
SPS at the top and LPS at the bottom / middle portion of the tank.
<< I wouldn't down grade your lights. Pricey as it may be, that sounds like
good lighting. If anything I'd switch to 150 watt double ended but I'd still
rather have your two 250 watt. >>
p/s: I have attached a photo of my tank, hope it helps.
Thanks for your precious time,
James
<< Blundell >>
|
|
 |
|
Ideal halide Kelvin rating?
Hi bob,
<< Blundell here. >>
I'm using 2 x 250W 20K BLV now, I love the soothing lightings & colours
of
the corals shown under it but I notice the PAR might not be strong
enough to
reach the corals at the tank bottom and also the Acros are not growing
as
fast. << Yes I have that exact type of lighting and problem. I really
like the 20k look but the amount of visual light given off is just way
too low. >> Have tried the 10K before, love the growth and PAR but
dislike the
bright whiteness of the light and also the corals ain't that colourful
when
compare with the 20K bulbs. Pls give me your advice.
<< You asked the right person. I've been looking into this heavily and
have decided (for the time being) that the Aqualine Busch bulbs are
probably the best. But the brand name is only somewhat important, the
main key (to looks and growth) I think is probably the new line of 14k's
now on the market. That is what I'm switching to. However, 10k's with
supplemental actinics is really nice as well. >>
regards,
James
<< Blundell >>
|
| |
|
